Condition: Brand New
Categories: CCTV & Security
Model: VB-8MP
Brand: OEM
SKU: VB-8MP-001
Weight: 50g (0.05Kg)
Shipping Methods:
Ratings: 95%
Products: 76
Response Rate: 100%
Response Time: ~ 5 minutes
Seller Country: Sri Lanka
We accept Credit cards, BinancePay & COD
Successful Islandwide Deliveries
Buyer Guard Protection
Easy 7days Return
Transmission Distance
|
CVBS |
Color video max up to 400m |
|
HD-AHD |
720P: Color video max up to 350m |
| 1080P,4MP,5MP,8MP: Color video max up to 200m | |
|
HD-TVI |
720P,1080P: Color video max up to 250m |
| 4MP,5MP,8MP: Color video max up to 200m | |
|
HD-CVI |
720P: Color video max up to 400m |
| 1080P: Color video max up to 250m | |
| 4MP,5MP,8MP: Color video max up to 200m |
Technical specifications:
|
Video Format |
HD-CVI/TVI/AHD, NTSC, PAL, and SECAM |
|
|
Frequency Response |
DC to 60MHz |
|
|
Attenuation |
0.5dB typ |
|
|
CMRR |
60 dB |
|
|
Surge protection |
4KV |
|
|
ESD |
8KV |
|
|
Impedance |
Coax, Male BNC |
75 ohms |
|
Terminal Block |
100 ohms |
|
|
Working environment |
Working Temperature |
-10℃ to +50℃ |
|
Storage Temperature |
-30℃ to +70℃ |
|
|
Humidity |
0 to 95% |
|
|
Wire Type |
UTP5 |
|
|
UTP Connection |
“Press-Fit” terminal blocks |
|
|
Power |
No power required |
|
|
Case |
ABS Plastic |
|
|
Dimension |
39mm*17mm*19mm(excluding connectors) |
|
|
Weight |
52g/pair | |
